重錘式料位計

產品概述

        ZL-1C型重錘式料位計適用于測暈敞口或密閉容器內粉料、顆粒料、塊料等的料位檢測，特別適合于冶金行業較大比重物料場合。它能幫助用戶及時準確地掌握料槽內物料的進料和消耗情況，以及在自動控制系統中作為槽位的自動控制和管理用，是物料儲運系統完全全自動無人操作的理想工具。

       該產品是我公司與寶鋼共同開發研制的項科技成果。它是我公司總結了1 0多年重錘式料位計制造、應用經驗、吸收了國外同類產品的優點后，在本公司原有產品基礎上優化改型的新產品。它采用了微電腦技術，具有結構簡單、定能穩定、安裝調試方便、功能強、適應面廣等優點。

ZL-1C type hammer type material level meter used in measurement exposure or airtight container in powder. pellet. the mass material material level detection, especially for in metallurgical industry for a large proportion of material occasions It can help users to timely and accurate grasp of the material in the chute feed and consumption, and the automatic control system as a slot of the automatic control and management, and is an ideal tool for material storage and transportation system fully automatic unmanned operation This produa is one of the scientific and technological achievements in the joint development of our company and Baosteel. It is summed up the compan'/ more than 10 years of heavy hammer type material position meter manufacturing and applicafion of experience. absorbing the advantages of similar foreign products. in the company's products on the basis of the original retrofit and optimization of new products It adopts microcomputer technology. which has the advantages of simple structure. stable stability. convenient installation and debugging, strong function. wide adaptability and so on

產品特點

使用重錘式探頭，工作可靠計暈準確、錘頭提升力矩大，可在進料或排料時使用。它可以應用在高粉塵、水蒸氣等場合的物料料位的檢測中。

具有過扭矩檢測和控制功能，能夠有效地保護電機，并使鋼絲繩在埋錘時玎不會被拉斷，過扭矩消失后能自動恢復到測定狀態。

具有自動測定、遙控測定、禁止測定等功能?？筛鶕?jù)用戶控制需要選用，還可適合車載式使用場合。

有6個可任意設定的高、低位報警點及2個自動生成的異常高、低報警輸出，可與各種系統自動控制功能配合使用。

具有料倉深度測量功能，可用于對未知深度的料槽進行槽深數據丈雖。

控制面板采用128X64 LCD多窗口中文顯示（或其它語種）。

在自動測定功能中，具有“T”、“T1+T2”、“C”三種測定間隔時間選擇，可以有效地防止溢料或空倉。

停電時用戶數據自動保存，復電后可自行恢復運行，無需重新設定數據

整機有多重機械及電氣保護，以廈故障自診斷控制輸出廈顯示功能，便于維護、檢修。

控制器電路結構合理并設置了多種抗干擾電路，可靠性高，抗干擾性能強。

控制箱采用雙重密封結構，防水防塵性能良好

Product features

The use of hammer type probe, reliable, accurate measurement, hammer lifting torque, can be used in charging or discharging time It can

be used in higYi dust, water vapor and other occasions the material level detection

Has torque detection and control function, can effectively protect the motor, and the wire rope in buried hammer also will not be pulled off.

torque disappeared after can automatically recover to the determination of state

With automafic measurement. remote control and other functions. determination of prohibIted determination According to user needs to

6 can be arbitra…y set high and low alarm points and 2 automatic generation of abnormally high. low alarm output. can be used with a

varietyof automatic control functions

With the depth bin measurement function. can be used for the trough of unknown depth of groove depth measurement data

Control panel using LCD 1 28X64 multi window Chinese display(or other languages)-

In an automatic measuring function. with "t". "T1. T2' and "C'- three determination time interval choice. can effectively prevent the overflow

of material or short positions

When power user data is automatically saved, the complex could return to operation, no need to reset the data

The machine has multiple mechanical and electrical protection. and fault self diagnosis output control and display function. convenient

maintenance and maintenance

The circuit struaure and set up reasonable coniroHer circuit, anti-lamming multiple high reliability. strong anti-jamming performance

The control box adopts double sealing structure. waterproof and dustproof performance is good
